PSDM-150W-24V CORE Lighting Magnetic Constant Voltage LED Driver – 150W 24V Dimmable-Fast Shipping

Description

CORE Lighting Constant Voltage Magnetic LED Driver in Junction Box, 150W Max Power Output, 120V Input, Fixed 24Vdc Output, 6500mA Max Output Current, Dimmable via MLV TRIAC (leading edge) Dimmers, NEMA 3R Junction Box

Please review replacement and order here: Exact Replacement

CORE Lighting 150W 24V Magnetic Constant Voltage LED Power Supply

Corelite LED Driver, Constant Voltage, Series: PSDM, Specifications: 150W Output, 120VAC, 24VDC Output, 6.5A Output, 2-Hole Flange Mounting, Metal Black Housing Knockouts

Max Power Output: 150W

Input Voltage: 120VAC,

Output Voltage Options: 24VDC

Current Output: 6500mA at Max Load

Dimming: Leading (forward) edge MLV TRIAC dimmer only (Note: Cap dimming leads if not dimming)

Auto Reset

UL Listed enclosure. Wiring compartment with 7/8″ knockouts

ETL Listed

Spec Sheets

CORE Lighting PSDM-150W-24V Spec Sheet
