LNE-36V100WDAA Delta CCCV Adjustable LED Driver – 100W Dimmable-Fast Shipping

Description

Delta LNE-36V100WDAA Configurable Constant Power (Adjustable current and voltage) LED Driver, 100W Max Power Output, 120-277V Input, adjustable output 18-36Vdc and 1325-2650mA, 3-way dimming (Rset, 1-10V, PWM)

Delta 100W CC+CV 2650mA / 36VDC Adjustable Dimming LED Driver

Programmable, Enabling Hundreds of Configurations – potentiometers to adjust output voltage & constant current (CC) level

Output Current Range: 1325-2650mA

Output Voltage Range: 18-36Vdc in CC mode and 33-40Vdc in CV mode

Dimming Controls: Analog (0-10V), PWM

IP67 and UL Dry/Damp Location

High surge immunity (common mode: 6kV, differential mode: 4kV)
