KTLD-100-UV-SC3000-56-VDIM-U4 Keystone Programmable Constant Current LED Driver – 100W 3000mA Dimmable-Fast Shipping

Description

Keystone SmartCurrent Constant Current Driver, 85W Max Power, Universal 120-277V Input, Programmable Fixed Output Current 1500-3000mA (factory default 3000mA), 10-56Vdc output, Analog 0-10V Dimming, IP20 dry and damp locations, Auxiliary Output

Keystone 100W 3000mA Constant Current Programmable LED Driver

Features

Output Power 100 Watt

Output Current: 1500-3000mA (factory set 3000mA) in 10mA increments

Output Voltage 10-56Vdc

Minimum Dimming Level: 1%, 3%, 5%,7%, or 10% (factory set 1%)

Dimming Curve: Linear, Log, Inverse Log, or Square-law (factory set Linear)

Auxiliary Power: 12Vdc; 200mA Max

UL Class P, Meets FCC 47 CFR Part 15 (Class B) Consumer Limits

Short Circuit Overload and Open Load Protection

Type 1 Outdoor, Suitable for Dry and Damp Locations

Class 2

Spec Sheets

KTLD-100-UV-SC3000-56-VDIM-U4 Spec Sheet
