E40R24DC Magnitude E-Series Constant Voltage LED Driver – 40W 24V Dimmable UL-Recognized-Fast Shipping

Description

Magnitude Lighting Constant Voltage LED Driver, UL Recognized, 40W Max Power, 120V Input, Fixed 24Vdc Output, Output Current up to 1750mA, Phase Dimmable 1%-100%, NEMA Type 6

Magnitude 40W 24V Constant Voltage LED Power Supply – UL Recognized

Max 40W LED Power Supply

Input Voltage: 120VAC, Output Voltage 24VDC

Output Current up to 1.75A

Dimming: phase-dimmable down to 1% with leading edge TRIAC dimmers

IP67, NEMA Type 6

Class 2 power supply

UL 8750 Listed, UL 879 – Standard for electric sign components

UL Recognized

E40R24DC-KO / E40R242DC – exact same unit

Spec Sheets

Magnitude E40R24DC Spec Sheet

Magnitude E40R24DC Installation Guide

Magnitude E-Series Dimmer Compatibility List
