Description
LED Density Illustration
About this item
- 635nm visible red rigid LED strip designed for red indicator lighting, decorative lighting, display lighting, and specialty red-light projects.
- Available in SMD2835 with 36 LEDs or SMD5050 with 30 LEDs per 50cm strip.
- Operates on DC 12V with a 120° beam angle.
- IP65 waterproof silicone-covered surface for indoor and protected outdoor installations.
- Rigid aluminum PCB helps improve heat dissipation and installation stability.
- Suitable for indicator lighting, decorative accent lighting, display lighting, showcase lighting, and visible red specialty applications.
- Each pack includes 1 × 50cm rigid LED strip.
- Dimmable with compatible DC12V dimmers.
Technical Specification
| Specification | SMD2835 | SMD5050 |
|---|---|---|
| Wavelength | 635nm Visible Red | 635nm Visible Red |
| Color | Visible Red | Visible Red |
| Voltage | 12V DC | 12V DC |
| LED Quantity | 36 LEDs/pc | 30 LEDs/pc |
| LED Type | SMD2835 | SMD5050 |
| Beam Angle | 120° | 120° |
| Length | 500 mm / 50cm per piece | 500 mm / 50cm per piece |
| PCB Type | Rigid aluminum PCB | Rigid aluminum PCB |
| Finish Color | Silver | Silver |
| Protection Grade | IP65 Waterproof | IP65 Waterproof |
| Dimmable | Yes, with compatible dimmer | Yes, with compatible dimmer |
Package Included
| Product Variant | Package Size | Package Included |
|---|---|---|
| 635nm SMD2835 36 LEDs | 50cm × 1 Pack | 1 × 50cm Rigid LED Strip |
| 635nm SMD5050 30 LEDs | 50cm × 1 Pack | 1 × 50cm Rigid LED Strip |
Order & Logistics
- Lead Time: Ships within 1–3 business days, occasionally 3–6 business days.
- Packing: Cardboard box.
- Shipping: From local warehouse (3–7 days) if available, or from HQ (9–18 days standard or 5–9 days express).
Other Features
| Feature | Details |
|---|---|
| Mounting | Rigid strip body can be fixed with suitable mounting accessories |
| Connector | DC connector / terminal connection depending on version |
| Polarity | V+ and V-; polarity sensitive |
| Application Type | Visible red lighting, indicator lighting, decorative lighting, display lighting |
Type of LED & Waterproof IP Grade
- SMD2835: 36 LEDs per 50cm strip, suitable for compact red light output and even illumination.
- SMD5050: 30 LEDs per 50cm strip, suitable for stronger single-chip light output.
- 635nm Visible Red: Red visible light designed for indicator lighting, decorative lighting, display lighting, and specialty red-light applications.
- Waterproof IP65: Surface covered with clear silicone to help protect against sprayed water from all directions.
Installation Tips
- Always disconnect the power supply before connecting LED strips.
- Do not bend rigid strips to avoid damaging the PCB.
- Do not connect LED strips directly to 120V AC power.
- Use a compatible DC12V power supply.
- Install only in dry indoor locations or protected outdoor environments.
- Apply power to test LED strips before final mounting.
Applications
- Visible Red Indicator Lighting
- Decorative Red Accent Lighting
- Display and Showcase Lighting
- Specialty Red-light Projects
- Cabinet, Shelf, and Signage Lighting
- Indoor and Protected Outdoor Lighting Applications
